Orange peel stucco embossed aluminum sheet coil is an aluminum alloy material with a special embossing process on the surface, forming a concave and convex texture similar to orange peel. Its unique physical and chemical properties make it widely used in many industrial fields.
Technical parameters
- Material: The mainstream uses 1060 (pure aluminum, good ductility) or 3003 (manganese alloy, high strength), and 5052 (magnesium alloy, seawater corrosion resistance) can be selected for special needs.
- Specifications: Thickness 0.15-1.5mm (conventional), up to 1.55 meters wide; plates above 5mm need to be customized (such as heavy equipment protection).
- Surface treatment: optional anodizing (enhanced hardness), color coating (colorful decoration), covering with polysurlyn film or polykraft paper (increase moisture proof and thermal insulating performance), covering with PVC film (transportation anti-scratch).
Core advantages of orange peel embossed aluminum sheet:
- Anti-slip performance
The surface orange peel texture significantly increases the friction coefficient, improves the safety of walking or equipment operation, and is especially suitable for humid and oily environments (such as cold storage floors and industrial platforms).
- Corrosion resistance and durability
The aluminum alloy substrate itself is corrosion-resistant. After superimposing the embossed texture, it further delays the penetration of corrosive media and prolongs the service life;
It can be anodized to form a dense aluminum oxide film, which enhances acid and alkali resistance and is suitable for chemical and marine environments.
- Heat dissipation and heat conduction efficiency
The texture expands the surface area by about 20%-30%, accelerates heat dissipation, and is widely used in refrigeration equipment (refrigerator liner, air conditioner heat sink) and solar reflective panels.
- Beauty and decorativeness
The texture lines are clear, and the color (silver, gray, black, etc.) and gloss can be customized to meet the aesthetic needs of modern buildings and products.
- Processing and environmental protection characteristics
Supports secondary processing such as cutting, bending, welding, and stamping, and is suitable for complex shapes;
100% recyclable, non-toxic and harmless, in line with green building standards.
- Easy to clean and maintain
The surface after anodizing is oil-repellent, and it is not easy to leave fingerprints or stains, reducing cleaning costs.
Orange peel embossed aluminum coils have penetrated into the industrial, construction and consumer fields with their versatility:
- Architectural decoration
Exterior wall curtain walls, roofs, ceilings, door and window frames, the function is to prevent corrosion and weathering, and enhance visual texture.
- Refrigeration and home appliances
Refrigerator/freezer liner, air conditioning ventilation pipe, condenser panel, the function is efficient heat dissipation and anti-condensation.
- Industrial protection
Pipeline insulation layer, chemical tank anti-corrosion, mechanical protective cover, the function is corrosion resistance, rust prevention, and extend equipment life.
- Transportation
Ship interior panels, truck compartment floors, subway handrail anti-skid plates, the function is weight reduction, anti-skid, and anti-vibration.
- New energy and environmental protection
Solar water heater reflectors, photovoltaic equipment shells, the function is high reflectivity and weather resistance.
- Furniture and packaging
Table and chair frames, cabinet panels; high-end gift boxes, bottle caps, the function is lightweight and beautiful decoration.
- Other fields
Reflectors for lamps, reinforcement layers for luggage, and housings for medical equipment. They are easy to clean and have stable structures.
Orange peel stucco embossed aluminum coils have the core advantages of anti-slip, corrosion resistance, heat dissipation, and lightweight, covering all scenarios from construction to cutting-edge equipment. With the upgrading of green manufacturing and industrial design, its application will further expand to new energy, smart home and other fields. When selecting, it is necessary to match materials and processes according to working conditions (such as corrosive environment and load-bearing requirements) to maximize performance benefits.
